The heating speed is fast, the temperature is easy to control and the production efficiency is high.
The operation of the resistance furnace is relatively simple, does not require any special skills or experience, and is easy to use.
The heat of induction heating is generated inside the workpiece itself, the heating is uniform, and the temperature difference between the core and the surface is extremely small. The application of temperature control system can achieve precise control of temperature, improve product quality and qualification rate.
The melting temperature rises quickly, the furnace temperature is easy to control, and the metal composition is uniform.
Resistance furnace smelting can obtain stable alloy composition and excellent physical properties, with stable and reliable quality.
It is convenient to change varieties and the furnace utilization rate is high.
| Equipment Type (Capacity) |
Power (Kw) |
Voltage (V) |
Matching Transformer (KVA) |
Cabinet Size (mm) |
Induction Coil Diameter
(mm) |
Weight
(T) |
|---|---|---|---|---|---|---|
| 1T | 800 | 3*660 | 1000 | 1400*850*2000 | Ф700 | 3.6 |
| 2T | 1500 | 3*660 | 1600 | 2300*1300*2000 | Ф860 | 7.4 |
| 3T | 2000 | 3*950 | 2500 | 2300*1300*2000 | Ф980 | 9.2 |
| 5T | 3000 | 3*950 | 3150 | 2300*1300*2000 | Ф1150 | 12.5 |
| 10T | 7000 | 3*1250 | 8000 | 2800*1300*2000 | Ф1450 | 22.1 |
| 15T | 10000 | 3*1250 | 12500 | 2800*1300*2000 | Ф1580 | 32.6 |
